Insta360 Pro 2
Better from every angle.
Insta360 Pro 2 8K Video Samples
Insta360 Pro 2 Detailed Specs
Lenses
6 x F2.4 fisheye lenses
Storage
6 x MicroSD cards + 1 x Full SD card
Power
12V 5A adapter
Material
Aluminum alloy
Exposure modes
Auto, Manual, Lens-by-Lens Custom, Shutter Priority (photo only), ISO Priority (photo only)
Diameter
φ143mm
Weight
~1550g
ISO Range
100~6400
Battery Capacity
5100mAh removable battery
White Balance Modes
Auto, Manual
Bitrate per lens
Up to 120Mbps
Video Files
MP4
Video Coding
H264 in-camera, H265 available when post stitching
Video
Post-processing Stitching:
7680 x 3840 @30 fps HDR (8K 2D)
7680 x 7680 @30 fps HDR (8K 3D)
7680 x 3840 @60 fps (8K 2D)
6400 x 6400 @60 fps (6K 2D/3D)
3840 x 3840 @120 fps (4K 2D/3D Binning)
Real-time Stitching:
3840 x 3840 @30 fps (3D)
3840 x 1920@30fps（2D）
4K Live Streaming
Modes: Built-in Server / Custom Server / HDMI output
4K 2D or 3D @30fps
Protocols: RTMP, RTSP, RTMPS, HLS
Simultaneous live streaming + recording for later 8K 3D production
8K Live Streaming
Using Insta360 8K Live*
Modes: Built-in Server / Custom Server / SDI output
8K 2D @30fps
Protocols: RTMP, RTMPS, RTSP
Simultaneous live streaming + recording of stitched 8K live stream
*License and PC required
Video Modes
Standard \ Binning
Note: i-Log is available in all modes and HDR is available in some modes.
Photo Files
JPEG / DNG
Photos
Real-time Stitching
7680 x 7680(3D)
7680 x 3840(2D)
Post-Processing Stitching
7680 x 7680 (3D)
7680 x 3840 (2D)
12000 x 12000 12K Super High-Res
(Multi-Photo Composite) (2D/3D)
Photo Modes
Single shot \ Burst (10 continuous shots) \ Timelapse \
AEB (Auto Exposure Bracket, optional 3, 5, 7, and 9 photos for in-camera HDR photos)
Note: Raw and JPG are both available in all modes
Video Transmission
Insta360 Farsight provides ground-to-ground range of up to 300 meters and ground-to-air range of up to 1000 meters, with 30 FPS preview.
Stabilization
Ultra-precise 9-axis gyroscope
Image Stabilization
FlowState stabilization
Antennae
GPS signal antenna + WiFi signal antenna
GPS
Built-in module
Ethernet Port
Yes
Control software
Windows / Mac / iOS / Android
WiFi specifications
802.11 b/g/n, 2.4GHz. Signal range is about 20 meters in open space. Max preview framerate of 30 FPS, supported in roughly 5-meter range.
Audio
4 Mono Mic
Video Color Space
YUVJ420P, offering a wide color range
Audio coding format
AAC
Spatial audio
Ambisonic
Stitching
Optical Flow / Template
Exposure Range
12 stop
Proxy File
Six low-res proxy files (one per lens) automatically saved in video mode; tailored for smooth editing in Adobe Premiere Pro
Features
Farsight Live Monitoring
FlowState™ Stabilization
8K 3D VR
HDR Video + Photo
360 VR live streaming
CrystalView 8K Playback
“No-Stitch” Editing in Adobe Premiere Pro
Spherical Audio
Specs
Diameter
Φ228mm
Material
Aluminum alloy
Lenses
8 x 200° F3.2 fisheye lenses
Photos
Real-time / Post-processing Stitching
10560 x 5280 (11K 2D)
10560 x 10560 (11K 3D)
Video
Post-processing Stitching
10560 x 5280 @30fps (11K 2D)
9600 x 9600 @30fps (10K 3D)
7680 x 7680 @50fps
7680 x 3840 @60fps
5248 x 2624 @120fps
10-Bit Video
7680 x 7680 @30fps (8K 3D)
7680 x 3840 @30fps (8K 2D)
Real-time Stitching
3840 x 3840 @30fps (4K 3D)
3840 x 1920 @30fps (4K 2D)
Photo Files
JPEG / DNG
Video Files
MP4
Video Coding
H264 and H265 in-camera, Pro RES 422 HQ is available when post stitching.
4K Live Streaming
Modes: Built-in Server / Custom Server / HDMI output
4K 2D or 3D@29.97fps
Protocols: RTMP, RTSP, RTMPS, HLS
Simultaneous live streaming + recording for later 8K 3D production
8K Live Streaming
Using Insta360 8K Live*
Modes: Built-in Server / Custom Server / SDI output
8K 2D@29.97fps
Protocols: RTMP, RTMPS, RTSP
Simultaneous live streaming + recording of stitched 8K live stream
*License and PC required
Storage Specification
9 × Full-size SD Cards
ISO Range
100~6400
Exposure Modes
Auto, Manual, Lens-by-Lens Custom, Shutter Priority (photo only), ISO Priority (photo only), Set ISO Upper Limit (video only).
White Balance Modes
Automatic, manual
Photo Modes
Single shot / Burst (10 continuous shots) / Timelapse /
AEB (Auto Exposure Bracket, optional 3, 5, 7, and 9 photos for in-camera HDR photos)
Note: Both RAW and JPG can be selected for simultaneous shooting for synthetic HDR photos and all other photo modes.
Video Modes
Standard (i-Log is available) / Binning (i-Log is available)
Bitrate Per Lens
Up to 180Mbps
Power
19V 9A adapter
Battery Capacity
10000mAh removable battery
Operating Temperature
0 – 40℃
Storage Temperature
-20 – 40℃
WiFi Specifications
WiFi Specifications: 802.11 b/g/n, 2.4GHz. Signal range is about 20 meters in open space. Max preview framerate of 30 FPS, supported in roughly a 5-meter range.
Antennae
GPS signal antenna + WiFi signal antenna
Ethernet Port
Yes
Video Transmission
Insta360 Farsight provides ground-to-ground range of up to 300 meters and ground-to-air range of up to 1000 meters, with 30 FPS preview.
Audio
4 Mono Microphones
Audio Coding Format
AAC
Spatial Audio
Ambisonic
Gyroscope
Ultra-precise 9-axis gyroscope
Stabilization
FlowState Stabilization
Stitching
Optical Flow / Template
Exposure Range
12 Stops
Supported Operating Systems
Windows / Mac / iOS / Android
Weight
5.5kg
Features
8× Micro Four Thirds Sensors
11K VR Photo + Video
Farsight Live Monitoring
FlowState Stabilization
360 VR Live Streaming
CrystalView 11K Playback
“No-Stitch” Editing in Adobe Premiere Pro
10-Bit Color
Insta360 Pro
Transport your audience: VR in 8K
Specs
UPC
Weight
Battery
Lenses
Material
Sound
Interface
360 videos
360 3D videos
360 photos
360 3D photos
File
Storage
Live-streaming
Dimensions
1228g
5100mAh removable battery (with 75 min of endurance) 12V 5A DC adapter
6 x F2.4 fisheye lenses
Aluminum alloy, polycarbonate
Built-in mic x 4 AUX
HDMI 2.0 Type-D (for the monitoring and output of footage) RJ45 Ethernet interface (for stable cable communication) USB Type-C (for high speed file transfer) WiFi (for AP hotspot connection)
Maximum at 3840×1920@30fps (4K) (real-time stitching/live-streaming) Maximum at 7680×3840@30fps (8K) (post-processing stitching)
Maximum at 3840×3840@24fps (4K) (real-time stitching/live-streaming) Maximum at 6400×6400@30fps (6K) (post-processing stitching)
Maximum at 7680×3840 (8K) (real-time stitching OR post-processing stitching)
Maximum at 7680×7680 (8K) (real-time stitching OR post-processing stitching)
MP4, JPG, RAW
SD card USB3.0 High-Speed driver
Up to 3840×3840 (4K) at 24fps H264 video coding and 3840×1920 (4K) at 30fps H264 video coding On any 360-supporting platform, including Facebook and YouTube
φ143mm
