General System

ECW220S

ECW230S

Model Name	ECW220S	ECW230S
Description	V1	V1
Radio Chain	2x2	4x4
Total Data Rate	1800 Mbps	3600 Mbps
WiFi Speed (2.4GHz)	574Mbps	1,148Mbps
WiFi Speed (5GHz)	1,200Mbps	2,400Mbps
Maximum Output Power(2.4GHz)	22dBm	23dBm
Maximum Output Power(5GHz)	22dBm	23dBm
Antenna Type	Internal Omni	Internal Omni
Antenna Gain (dBi) @ 2.4GHz	3dBi	5dBi
Antenna Gain (dBi) @ 5GHz	3dBi	5dBi
PoE Input	802.3af	802.3at
Maximum Power Comsuption	12.5W	20.4W
Deployment Option	Cloud-managed	Cloud-managed
Application	Indoor	Indoor
Ethernet Port & Link Rate	1 x Gigabit	1 x Multi Gigabit
Housing (Plastic)	Yes	Yes
Housing (Metal)	Yes	Yes
Wall Mount	Yes	Yes
Ceiling Mount	Yes	Yes

Wireless Mode

Access Point (AP)	Yes	Yes
Mesh	Yes	Yes
