Anti-theft Heavy-duty Tilting Curved & Flat Panel TV Wall Mount


Easy to use and install, the popular model LP22-46T is designed to fit any 37”-70″ curved & flat panel TVs up to 45kg/99lbs. It features preset height and leveling adjustments that allow TV to be perfectly positioned after hanging. This unit mounts in tilting position and tilts up to a 15° to position the screen for an optimal viewing experience. Strength has been tested for a minimum of four times its stated load capacity. The locking bar provides anti-theft function which will require a padlock. It also has side decorative caps for an elegant look. Compatible with VESA hole up to 600×400.


  • Easy-Grip Knobs: for quick tilt and lock
  • Leveling adjustments: allow TV to be perfectly positioned after hanging
  • Integrated Bubble Level: assures alignment
  • Anti-Theft Locking Bar: for additional security preventing any unwanted removal (extra padlock required)
  • Decorative Covers: for a more elegant look


Product Category: Tilt TV Wall Mount
Rank: Standard
Material: Steel,Plastic
Metal Sheet Thickness: Bracket Arm THK=1.5mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet(Bracket Arm THK=0.059" cold-rolled sheet,Wall Plate THK=0.079" cold-rolled sheet)
Surface Finish: Powder Coating
Color: Fine Texture Black
Dimensions: 59x715x440mm(2.3"x28.1"x17.3")
Fit Screen Size: 37"-70"
Fit Curved TV: Yes
Mounting Hole Pattern: VESA & Universal
VESA Compatible: 200x200,400x200,300x300,400x400,600x400
Max. Mounting Hole: 600x400
Weight Capacity: 45kg(99lbs)
Strength Tested: 4 Times Approved
Profile: 59mm(2.3")
Tilt Range: -15° ~+10°
Screen Level: ±8mm
Installation: Solid Wall,Double Stud(406mm/450mm/600mm)
Panel Type: Detachable Panel
Wall Plate Type: Fixed Wall Plate
Wall Plate Type: Fixed Wall Plate
Cable Management: No
Anti-theft: Yes
Bubble Level: Built-in Bubble Level (Integrated on Wall Plate/VESA Panel)
Accessory Kit Package: Normal/Ziplock Polybag,Compartment Polybag
Instruction Manual Included: Yes
Samsung Screw Kit: No
By Function: Tiltable

Package Information

Package: Type: Gift Box
Unit Packing Size: 73.5x16.5x5CM
Volume: 0.01
Unit GW/NW: 3.50KG/3.120KG
Carton Size: 75x22x18CM
Q'ty/Carton: 4
GW/NW: 15KG/12KG
Q'ty/20'GP: 3636
Q'ty/40'GP: 7540
Q'ty/40'HP: 8616
